● 50% duty cycle, variable frequency control of resonant half-bridge
● High-accuracy oscillator
● Up to 500kHz operating frequency
● Two-level OCP: frequency-shift and latched shutdown
● 50% duty cycle, variable frequency control of resonant half-bridge
● High-accuracy oscillator
● Up to 500kHz operating frequency
● Two-level OCP: frequency-shift and latched shutdown
● Interface with PFC controller
● Latched disable input
● Burst-mode operation at light load
● Input for power-ON/OFF sequencing or brownout protection
● Non-linear soft-start for monotonic output voltage rise
● 600V-rail compatible high-side gate driver with integrated bootstrap diode and high dV/dt immunity
● -300/800mA high-side and low-side gate drivers with UVLO pull-down
● DIP-16, SO-16N packages
